Cylindrical lithium batteries are among the most widely used rechargeable batteries in the world. Known for their durability, energy density, and efficiency, they are used in numerous applications, from consumer electronics to electric vehicles (EVs). Their cylindrical shape offers structural stability, which makes them more resistant to internal pressure compared to other battery forms like pouch or prismatic batteries.
Cylindrical lithium batteries are typically classified by their size, voltage, and capacity. The model names consist of five numbers that denote the battery’s dimensions (diameter and length in millimeters). Here's a comprehensive list of common cylindrical lithium battery models:
Dimensions: 18mm in diameter, 65mm in length
Voltage: Typically 3.6V - 3.7V
Capacity: 1200mAh to 3500mAh
Applications: Laptops, power tools, electric vehicles, flashlights
Dimensions: 21mm in diameter, 70mm in length
Voltage: Typically 3.6V - 3.7V
Capacity: 3000mAh to 5000mAh
Applications: Electric vehicles (Tesla Model 3), portable electronics, power tools
Dimensions: 26mm in diameter, 65mm in length
Voltage: Typically 3.6V - 3.7V
Capacity: 3000mAh to 6000mAh
Applications: Flashlights, electric bicycles, portable power stations
Dimensions: 14mm in diameter, 50mm in length
Voltage: Typically 3.6V - 3.7V
Capacity: 600mAh to 900mAh
Applications: Compact electronic devices, flashlights, remote controls
Dimensions: 32mm in diameter, 65mm in length
Voltage: Typically 3.2V - 3.7V
Capacity: 5000mAh to 7000mAh
Applications: Solar power storage, electric vehicles, industrial applications
Dimensions: 10mm in diameter, 44mm in length
Voltage: Typically 3.6V
Capacity: 300mAh to 600mAh
Applications: Penlights, small electronics
Dimensions: 18mm in diameter, 35mm in length
Voltage: Typically 3.7V
Capacity: 700mAh to 1200mAh
Applications: Vaporizers, portable devices
Dimensions: 20mm in diameter, 70mm in length
Voltage: Typically 3.7V
Capacity: 3000mAh to 4250mAh
Applications: Electric bikes, power tools
Dimensions: 14mm in diameter, 25mm in length
Voltage: Typically 3.6V
Capacity: 300mAh to 400mAh
Applications: Medical equipment, small electronics
Cylindrical lithium batteries, like all lithium-ion batteries, rely on the movement of lithium ions between the anode (typically made of graphite) and the cathode (typically made of lithium compounds) during charging and discharging. When the battery is charged, lithium ions move from the cathode to the anode, and during discharge, the ions return to the cathode, releasing energy to power devices.
Their cylindrical structure is highly efficient for thermal management, making them suitable for high-drain applications. The design also allows for uniform current distribution and minimizes internal resistance, which enhances battery life and performance.
Structural Durability: Cylindrical lithium batteries have a robust steel casing that offers better resistance to physical stress.
Thermal Management: Due to their shape, these batteries have a large surface area, which helps in dissipating heat more effectively.
High Energy Density: Cylindrical batteries offer a higher energy density compared to traditional battery chemistries, making them ideal for compact devices.
Scalability: Their standardized sizes (such as 18650 or 21700) make it easy to use multiple batteries in parallel or series for different applications.
Cost Efficiency: Mass production of standardized models like the 18650 has lowered the cost, making cylindrical lithium batteries affordable for various applications.
Cylindrical lithium batteries are extensively used in consumer electronics like laptops, cameras, and power banks due to their high energy density and long lifespan.
Batteries like the 18650 and 21700 are commonly used in electric vehicles due to their scalability, safety features, and energy efficiency. Tesla, for example, uses 21700 cells in their Model 3 vehicles.
Cylindrical lithium batteries are ideal for power tools due to their durability and ability to deliver high currents.
The high energy density and long cycle life of cylindrical lithium batteries make them suitable for renewable energy storage solutions, such as solar panel battery banks.
Although cylindrical lithium batteries are designed with safety in mind, they still require proper handling and management systems. Common safety measures include:
Overcharge Protection: Prevents excessive voltage buildup.
Overheat Protection: Stops the battery from overheating, reducing the risk of explosion or fire.
Short Circuit Protection: Protects the battery from short circuits that could cause damage.
Energy Density Limitations: While cylindrical lithium batteries offer high energy density, there are ongoing efforts to improve capacity and extend battery life further.
Recycling Issues: The disposal and recycling of lithium batteries remain a challenge due to the environmental impact of lithium mining and the complexity of battery recycling processes.
Technological Advancements: Future developments include solid-state batteries that could offer even higher energy densities and better safety profiles compared to current lithium-ion technology.
Cylindrical lithium batteries have become the backbone of modern energy storage solutions, thanks to their durability, efficiency, and versatility. Whether it’s powering an electric vehicle, a power tool, or a portable electronic device, these batteries continue to evolve, offering new possibilities in energy storage and management.
What is the difference between 18650 and 21700 batteries?
The main difference lies in their dimensions and capacities. 21700 batteries are larger and generally offer more capacity than 18650 batteries.
Can I replace 18650 batteries with 21700 batteries?
Not necessarily. It depends on the device specifications. The device must be compatible with the larger size of 21700 batteries.
How long do cylindrical lithium batteries last?
Cylindrical lithium batteries typically last 300 to 500 charge cycles, depending on usage conditions.
What are the safest cylindrical lithium batteries?
Lithium iron phosphate (LiFePO4) cylindrical batteries are considered safer due to their thermal stability and lower risk of overheating.
How should I store cylindrical lithium batteries?
Store them in a cool, dry place away from direct sunlight. Ideally, keep them at 40-50% charge if not in use for extended periods.
